LED Neon Flex Goodpex™
更新时间：2010-07-30
LED Neon-Flex™ Plus is the next generation of patented LED Neon-Flex™ with light output equivalent to glass neon.
Description
+ Plus has been engineered to achieve a lumen efficacy of 36.1Lm/w and 63Lm/Ft. LED Neon-Flex™ for the first time can now be viewed as direct replacement to traditional glass Neon.
The increased lumen output is a direct result of using high quality materials, high brightness LEDs coupled with an enhanced PVC mixture used in the main housing extrusion process. This optical gain enhancing PVC increases homogenization of the light effect which translates the maximum amount of lumens consistently delivered to the surface of the Neon-Flex™ Plus.
In comparison to white glass neon, the luminous efficacy of white +Plus achieves an equivalent brightness of 36.1Lm/W while using 6.6 times less energy. The Lumens efficacy and power consumption of the primary colors red, green, blue, Orange and yellow LED Neon-Flex™ Plus are significantly comparable to glass neon as well.
LED Neon Flex™ +Plus colors include White, Warm White, Ultra-Warm White, Red, Yellow, Orange, Blue, Green and Hot Pink.
Benefits
- UL/CUL E126962
- 3 Year Limited Warranty
- Consistent and Stringent Wavelength control standards +/-5nm
- New Ultrabright LEDs
- Flexible
- Unique PVC double jacket design
- White PVC Base Layer to increase luminosity
- Durability, Impact Resistant.
- Weather Resistant
- Low Voltage Options
- Low Heat
- Longer Life
- Easy to Install
- Extremely Low Maintenance Costs
- 70% less energy consumption of glass neon
- Does not interfere with Video/Audio systems nearby.
Product Types
- 24V, 120V, 240V AC/DC
- Color Jacket & Opaque Jacket
Availability
- Stocked Item, ships within 48 hours.
- Factory direct pricing available, allow 4 - 7 weeks delivery.
High Output with Even Brightness
LED Neon Flex™ Plus is comprised of a string of LED’s spaced at a specific distance apart that illuminates our patented oval-shaped diffuser to produce light with uniformity of neon-like brightness with no chromatic aberrations.
LED Neon-Flex™ Plus VS Glass Neon Chart
| Parameter | LED Neon-Flex™ Plus Replacement | Ø8 Glass Neon | LED Neon-Flex™ Plus (Benefits) over Glass Neon |
| 3Ft. White LED Neon-Flex™ Plus | 3Ft. White Common Ø8 Glass Neon | ||
| Light Source: | LED | Neon Gas Fluorescent | LED is solid state semi conductor technology which offers great benefits in energy savings and environmental protection |
| Input Voltage: | 24V/120V/240V | 3KV-18KV | >LED Neon-Flex™ Plus safely operates at 12, 24, 120 and 240 Volts. Glass neon often operates at 15,000 Volts producing lots of heat making it a fire hazard. |
| EMI (Electro Magnet Interference) | LOW | HIGH | LED Neon-Flex™ Plus creates insignificant EMI compared to Glass Neon |
| Luminous Efficacy (Lm/W) | 36.1 | 35 | 3% higher |
| Lm/Foot | 63 Lm/Ft. | 59.15 Lm/Ft. | LED Neon-Flex™ Plus Lm/FT exceeds that of Glass Neon by as much as 6% with Red. |
| Environmental Considerations | No Mercury Pollution | Mercury Pollution | LED Neon-Flex™ Plus is safe for the environment and the public as it contains no toxic materials like Mercury which is found in Glass Neon |
| Installation | Easy/Entry Skill Level | Difficult/Requires Master Craftsmanship Skill Level |
LED Neon-Flex™ Plus is flexible, and is easy to cut, bend, and shape, unlike Glass Neon which requires a master craftsman level of experience to produce, shape, and install. |
| Flexibility | Flexible | Rigid | LED Neon-Flex™ Plus is a flexible solution that requires no heating to bend or shape. |
| Durability | Unbreakable | Breakable | LED Neon-Flex™ Plus is made of high quality flame retardant PVC's and is flexible unlike Glass which shatters easily. |
| Warranty | 36 Months Limited Warranty | No Warranty against Breakage | LED Neon-Flex™ Plus is very dependable. Manufacture defects will be replaced for 36 months. |
LED Neon Flex™ Plus & Color Jacket Plus Specifications
|
Item No.
|
LN-FX-P-50M-240V
|
LN-FX-P-150FT-120V
|
LN-FX-P-150FT-24V
|
| Voltage |
240V AC
|
120V AC
|
24V DC
|
|
Roll Length
|
49.4 Meters
|
150 Feet
|
150 Feet
|
|
LED Spacing
|
12.7mm
|
12.7mm
|
12.7mm
|
|
Cutting Unit
|
1.52M(R,Y,O)
|
2.5Ft(R,Y,O)
|
4"(R,Y,O)
|
|
0.91M(B,G,W)
|
1.5Ft(B,G,W)
|
3"(B,G,W)
|
|
|
Watt/Unit
|
3.94W/M(R,Y,O)
|
1.2W/Ft(R,Y,O)
|
1.8W/Ft (R,Y,O)
|
|
5.25W/M(B,G,W)
|
1.6W/Ft(B,G,W)
|
1.92W/Ft(B,G,W)
|
|
|
Max Load
|
97M(R,Y,O)
|
160Ft(R,Y,O)
|
150 Watts/6Amps DC |
|
73M(B,G,W)
|
120Ft(B,G,W)
|
Light Output +Plus Series
|
Color
|
Red
|
Yellow
|
Orange
|
Blue
|
Green
|
White
|
|
Total Output (Lm/Ft)
|
25.6
|
24.1
|
25.8
|
37.5
|
53.5
|
63
|
